Different types of freezer rooms operate at different temperature levels depending on the products being stored. For international buyers, the key concerns are always the same:
What temperature should the freezer room run at? How much does it cost to build? How much can it store?
1. Common Temperature Standards for Low-Temperature Freezer Rooms
1. -18°C Freezer Room (Frozen Meat Storage)
- Standard temperature: -18°C (±5°C adjustable)
- Used for storing meat that has already been rapidly frozen at -35°C.
- Ensures long-term storage without texture loss.
2. -30°C to -35°C Blast Freezer Room
- Temperature range: -30°C to -35°C
- Used for rapid freezing of food, seafood, fruit, and raw materials.
- High freezing speed = better taste and less drip loss.
3. Ultra-Low Temperature Freezer Room (-60°C to -80°C)
- Temperature range: -60°C to -80°C
- Used for tuna, sashimi-grade seafood, biological samples, and pharmaceuticals.
- Maintains cellular integrity for premium seafood export and lab storage.
4. Special Freezer Rooms (-100°C and below)
- Temperature: -100°C to -120°C
- Used for environmental simulation, research labs, and special biological materials.
2. How Much Does It Cost to Build a Low-Temperature Freezer Room?
Cost varies by temperature requirement, insulation thickness, compressor configuration, and project location.
General pricing (converted from RMB → USD):
| Freezer Type | Temperature | Cost per m² (USD) | Notes |
|---|---|---|---|
| -18°C Freezer Room | -18°C | $360–380 / m² | Most common frozen storage |
| -35°C Blast Freezer | -30°C to -35°C | $480–580 / m² | Higher-capacity refrigeration |
| -60°C Tuna Freezer | -50°C to -60°C | $800–1200 / m² | Premium insulation required |
| -80°C Ultra-Low Room | -70°C to -80°C | $1500–2000 / m² | Lab-grade system |
Example:
A 100 m² -35°C blast freezer typically costs:
➡️ USD 48,000 – 58,000
(including panels, compressors, evaporators, electrical system, installation, and testing)
3. Storage Capacity of Low-Temperature Freezer Rooms
Storage volume depends on room height (usually 3–4 m):
Example: 100 m² freezer room
- Volume: ~350 m³
- Storage capacity:
- Frozen meat: 65–90 tons
- Seafood: 55–80 tons
- Blast-frozen food: 50–70 tons
- Pallets: 80–120 pallets
4. Electricity Consumption
Typical energy consumption for low-temperature freezer rooms:
- -18°C freezer: 45–65 kWh per ton per day
- -35°C blast freezer: 70–110 kWh per ton per day
- Ultra-low: -60°C to -80°C: 120–180 kWh per ton per day
Good engineering design reduces power usage by 10–18%.
Investment & ROI Example
A client in Santiago, Chile built a 150 m² -35°C blast freezer room for frozen beef and seafood export.
- Investment Cost: ~USD 78,000
- Storage Capacity: ~75–95 tons after blast freezing
- Energy Consumption: 75–110 kWh per ton per day
- Payback Period: 1.5–2.3 years, thanks to high demand for frozen beef and strong export margins
